Dust filter bags

550g PPS / PTFE Dust Filter Bags for Power Plants

PPS Dust Filter Bags Details :


Material : 100% or customized China PPS , Toray PPS
Scrim : PPS , PTFE
Weight : 500-650g/m2
Optional process: Sewing or hot welding
Finish-treatment: Calendering, Heat setting, Singeing



  • Item NO.:

    PPS PTFE-01
  • Payment:

    L/C, T/T, D/P, Western Union, Paypal
  • Product Origin:

    China
  • Shipping Port:

    Shanghai, China
  • Lead Time:

    7
  • Scrim Material:

    100%PTFE
  • Weight:

    580-680 gsm
  • Thickness:

    1.8±0.2mm
  • Temp. Range:

    Continue 170℃ Peak 210℃
  • Application:

    Power Plant,Steel
  • Product Detail

550g PPS / PTFE Dust Filter Bags for Power Plants


1. Brief Introduction

Other PPS Dust Filter Bags Customzied by your working conditions .The PPS Dust Filter Bags add the PTFE fiber can improve the oxidation and temperature resistance .
1. 50% PPS +50% PTFE / PTFE
2.30% PPS +70% PTFE / PTFE
3.100% PPS / PTFE
4.70% PPS +30% PTFE /PTFE



2、Technical data

Technical Specification

Name/Quality

PPS+PTFE

Component

Shell Fiber

PPS+PTFE

Scrim

PTFE

Weight

550±5% gsm

Thickness

1.8±0.2mm

Air Permeability /200Pa  L/dm2.min

120-150

Tensile Strength   N/5*20CM

Length

900

Cross

≥1200

Elongation at break %

Length

10

Cross

≤50

Temperature                                          ( Celsius Degree)

Continue

170

Peaks

210

Finish

Singeing,Calendering,Heat-set,PTFE membrance,Impregnation,WOR

Use Scope

Power Plant,Steel


3. Remarks
1) The length of dust filter bags:  can be customized
Usual size: diameter 100mm, 125mm, 130mm, 150mm, 180mm, 250mm ect.
2) Process Method: automatic sewing or welded
3)Production details: Double bottoms and reinforcement to make abrasion resistance. Sewing thread: PTFE thread, polyester thread.
4)Inspection:  Filter bags will be according to the national standards, industrys standards and enterprise standards.
5) If your required filter bag is different from our usual one, then please send us your drawing picture and choose material you need since we also produce the nonstandard filter bag.


4. Yuanchen Service

1.Various material: Polyester(PE), Polypropylene (PP), Aramid, P84, Acrylic, PPS, Fiberglass, PTFE, Nomex, FMS etc.
2.Strong intensity
3.Excellent anti-abrasion, good finishing treatment such as water and oil proof
4.Good raw material, competitive price
5.High filtration efficiency
6.Fast delivery
7.Size can be customized
8.Factory manufacturer could control quality and price
9.Strictquality inspection and control
10.Professional designer teams to match with your operating condition


5. Application field:

• Power generation
• cement
• Coal - Fired Boilers bag houses
• Municipal Solid Waste Boilers and Waste incinerator
• Combustion processing
• Dryers
• Waste to energy
• Iron and non ferrous Metal Industry


6. Package:

Different types of filter bag must be individually packaged. In general, it is wrapped in plastic bags for water proof, then put in a carton. Filter bag must be neat and regular packing, with the ring of the filter bag to avoid ring flat compression deformation. For the requirement to keep the shape of filter bag, it must fill padding for filter bag inside. Any other packing ways also be accepted up to you.


7. FRQ:

  Q1. What is your terms of payment?
  A: T/T will usually be accepted, details could be negotiated.
  Q2. What is your terms of delivery?
  A: FOB, CFR, CIF, DDU,EXW
  Q3. How about your delivery time?
  A: Generally, it will take 10to 20 days after receiving your advance payment.
       The specific delivery time depends on the items and the quantity of  your order.
  Q4. Can you produce according to the samples?
  A: Yes, we can produce by your samples or technical drawings.
  Q5. What is your sample policy?
  A: we could offer the sample for free charge but do not pay the cost of freight.
  Q6. Do you test all your goods before delivery?
  A: Yes, we have 100% test before delivery
  Q7: How do you make our business long-term and good relationship?
  A:1. We keep good quality and competitive price to ensure our customers benefit ;
      2. We respect every customer as our friend and we sincerely do business and make  friends with them.
