Dust filter bags

Galvanized Steel Bag Cage

Wire Cages are professionally manufactured, constructed from galvanized or stainless steel and welded for structural stability.


  • Item NO.:

    Bag Cage-gf-01
  • Product name:

    Filter Bag Cage
  • Size:

    Customized
  • Material:

    Galvanized Steel
  • MOQ:

    1 piece
  • Product Detail

Filter Bag Cage for Baghouse Filter

Dimensions:


A. Round Style

Diameter (mm)

Bag Diameter (mm)

Length (mm)

115

120

2000;  2400;  2800

3200;  3600;  4000

4400;  4800;  5200

5600;  6000

125

130

147

152

195

200


B. Flat Style

Perimeter (mm)

Bag Perimeter (mm)

Length (mm)

800

800

2000; 3000; 4000

900

900

5000; 6000


C. Envelope Style

Length Width Thickness (mm)

Bag - Length Width Thickness (mm)

1500*750*25

1500*750*25

Leave A Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Related Products
PTFE Sewing Thread
PTFE Sewing Thread For Filter Bags
Specifications: Feature: Industry Sewing Thread Product Name: 100% Spun PTFE Sewing Thread Pattern: filament Free samples: yes OEM: yes
Filter Bag Cage
Silicone Coating Filter Bag Cage
The filter bag cage is the support of filter bag and it should be light and easy for installation and maintenance. The quality of filter cage has directly bearing on the filtering state and service life of a filter bag. Every cage we make can meet the requirement for tightness, smoothness and uprightness.
Filter Bag Cage
Stainless Steel Bag Cage
Yuanchen manufactures a wide range dust collector filter cages to fit all baghouse makes and models. We can also manufacture uncommon and specialized cage designs as required.
Composite Filter Bag
550g PPS / PTFE Dust Filter Bags for Power Plants
PPS Dust Filter Bags Details :  Material : 100% or customized China PPS , Toray PPS  Scrim : PPS , PTFE  Weight : 500-650g/m2  Optional process: Sewing or hot welding Finish-treatment: Calendering, Heat setting, Singeing
FMS Filter Fabric
FMS Dust Removal Sleeve Bag for Cement Dust Collector
Long-term temperature resistance of 260℃, instantaneous temperature resistance of 300℃, is a kind of filter material with excellent high temperature resistance, acid and alkali resistance. It has various characteristics as a high-performance fiber; it can resist a variety of acids, alkalis and Chemical corrosion of oxidizer; has good hydrolysis resistance; typical applications are Cement,Waste Incineration.
PTFE Filter Bags
Non-woven Filter High Temperature Resistant PTFE Filter Bag
The PTFE filter bag is a unique material made of filter bag. It can withstand the acid-base erosion in the whole pH range under the temperature from 240 °C to 260 °C. The PTFE  filter bag is excellent in self-lubrication, does not absorb moisture, and can withstand ultraviolet radiation. However, the PTFE fiber filter material has a general wear resistance, so there is a strict requirement (cleanness) for the filter bag frame. PTFE fiber filter bags are suitable for use in harsh conditions where corrosion resistance is required and where filter media life requirements are high.
Polyester Filter Bag
Striped Antistatic Polyester Filter Bag for Chemical Plant
Dust collection bags play an important role in the development of modern industry and are widely used in the environmental protection of atmospheric dust in the food, chemical, biomass power generation, and pharmaceutical industries. PTFE dust bag has excellent performance under certain harsh operating conditions, such as strong temperature resistance, abrasion resistance, corrosion resistance, chemical resistance, high filtration efficiency, low running resistance, long service life, etc. Advantages, so it is widely used in various harsh flue gas filtering environments such as steel, electricity, garbage incineration, etc.
PPS filter cloth
PPS/Ryton Needle Punched Filter Felt Filter Cloth
Needle felt is a kind of non-woven filter fabric specially used for dust collector filter bags. It is a major filter material for industrial air filtration and dust removal. The needle felt is made of randomly arranged fibers needle punched on the scrim fabric, after that the fibers are close-knitted to form a tortuous three-dimensional stereo-structure, which is different from the traditional woven filter cloth composed of warp and weft yarns. It makes dust particles adhere to the surface of the filter material and form an initial layer of dust ( Filter cake), with the remarkable characteristics of small pore size, high filtration efficiency and low air resistance, greater air permeability and excellent dust particle capture.
