dust collector system fiberglass filter bag
1. Brief Introduction Of Fiberglass YUANCHEN filter bag for cement industry dust collector
Different weight:350gsm/550gsm/750gsm
Different color:black/light yellow/white
Different surface treatment:silicon/graphite PTFE coating/membrane
2. Technical Data
| Material |
Temperature |
Application |
|
Fiberglass mixed polyester |
180-220 Degree C |
Steel Plant ,Chemical Plant |
|
Fiberglass mixed Aramid |
220-250 Degree C |
Chemical Blast furnace gas |
|
Fiberglass mixed PPS and PTFE |
240-260 Degree C |
Coal-fired boiler ，biomass boiler |
|
Fiberglass mixed PPS |
200-230 Degree C |
Coal-fired boiler ，biomass boiler |
|
Fiberglass mixed P84 |
240-280 Degree C |
Cement Kill |
3. Remarks
1) The length of dust filter bags: can be customized
Usual size: diameter 100mm, 125mm, 130mm, 150mm, 180mm, 250mm ect.
2) Process Method: automatic sewing or welded
3) Prodction details:Double bottoms and reinforcement to make abrasion resistance.
Sewing thread: PTFE thread, polyester thread.
4) Inspection: Filter bags will be according to the national standards, industry standards and enterprise standards.
5) If your required filter bag is different from our usual one, then please send us your drawing picture and choose material you need since we also produce the nonstandard filter bag.
4. Feature
1. High Temperature Resistance:240-280
2. Excellent Acid and Alkali resistance
3. Abrasion resistance, high tensile strength
4. Low resistance of filtration
5. Single fiber, high porosity, gas filtration resistance
6. Can be used in a variety of complex situation and harsh environmental conditions
5. Application field:
Suitable for cement ,coal burning boiler,garbage incineration,steel making electric furnace,blast furnace gas,ferroalloy furnace and other high temperature flue gas and dust collection.
6. The fiberglass filter bag socks packaging:
Different types of filter bag must be individually packaged. In general, it is wrapped in plastic bags for water proof, then put in a carton. Filter bag must be neat and regular packing, with the ring of the filter bag to avoid ring flat compression deformation. For the requirement to keep the shape of filter bag, it must fill padding for filter bag inside. Any other packing ways also be accepted up to you.
7. FRQ:
Q1. What is your terms of payment?
A: T/T will usually be accepted,details could be negotiated.
Q2. What is your terms of delivery?
A: FOB, CFR, CIF, DDU,EXW
Q3. How about your delivery time?
A: Generally, it will take 10to 20 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q4. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q5. What is your sample policy?
A: we could offer the sample for free charge but do not pay the cost of freight.
Q6. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q7: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them.
